DIY Infrared Sauna Heater Kit – 4 Carbon Fiber Heating Panels + 3 Full Spectrum Infrared Heaters
This DIY infrared sauna heater kit is designed for sauna repair, sauna upgrades, and custom DIY infrared sauna builds. It combines 4 carbon fiber far infrared heating panels with 3 full spectrum infrared heater modules for comfortable heat coverage and faster warm-up performance.
Product Overview
Compared with a sauna heater kit using only carbon fiber heating panels, this hybrid heating system can heat up approximately 30% faster. It is ideal for customers who want stronger heating performance, better heat coverage, and a more comfortable infrared sauna experience.
This kit is suitable for DIY infrared sauna room builds, sauna heater replacement, sauna repair projects, and upgrades for small to medium infrared sauna rooms.
Package Includes
| Carbon Fiber Infrared Heating Panels | 4 pcs |
| Full Spectrum Infrared Heater Modules | 3 pcs |
| Installation Tools | Screw Pack |
| C13 Connector Wiring Harness | 7 pcs + 1 pcs 2-in-1 Connector |
| Wire Length | 2 meters / approx. 6.6 ft × 7 |
| Connection Design | Plug-and-play style connection for compatible sauna controller systems |
Product Details
| Product Type | DIY Infrared Sauna Heater Kit |
| Heating System | Carbon Fiber Far Infrared Heating Panels + Full Spectrum Infrared Heaters |
| Carbon Fiber Heating Panel Quantity | 4 pcs |
| Carbon Fiber Heating Panel Size | 40 × 100 cm / 15.7 × 39.4 in |
| Carbon Fiber Heating Panel Power | 320W each |
| Full Spectrum Infrared Heater Quantity | 3 pcs |
| Full Spectrum Infrared Heater Size | 76 × 20 cm / 29.9 × 7.9 in |
| Full Spectrum Infrared Heater Power | 350W each |
| Total Power | 2330W |
| Recommended Max Sauna Size | 1.5 × 1.3 × 1.9 m |
| Recommended Max Sauna Size in Feet | 4.9 × 4.3 × 6.2 ft |
| Recommended Max Sauna Volume | Approx. 3.7 m³ / 131 cu. ft. |
| Maximum Temperature | Approx. 65°C / 149°F |
| Housing Material | Canadian Hemlock Wood |
| Connector Type | C13 connector wiring harness |
| Controller Compatibility | Compatible with all sauna controllers sold on our website |
Power Requirements
This heater kit has a total power of 2330W. Before installation, please make sure your sauna controller, circuit, outlet, wiring, and plug are rated for the total power load.
| Total Power | 2330W |
| Current at 120V | Approx. 19.4A |
| Current at 240V | Approx. 9.7A |
| Recommended Voltage | 240V is recommended for better electrical safety margin and more stable operation |
| 120V Use | Not recommended on a standard 120V 20A circuit because the total load is close to the circuit limit. If only 120V is available, use a dedicated circuit or remove one heating element. |
| Recommended Circuit | Dedicated circuit with proper breaker, outlet, plug, and wire size based on local electrical code |
| Installation Note | If your installation involves main power wiring, circuit changes, or voltage changes, please use a qualified electrician |
Important: This heater kit can be used with compatible sauna controllers, but the controller power rating, voltage, plug type, wiring, and circuit capacity must match the heater kit. Do not connect this kit to an undersized circuit or an incompatible controller.
Key Features
Hybrid Infrared Heating System
This kit combines carbon fiber far infrared heating panels and full spectrum infrared heaters. The carbon fiber panels provide smooth, even, and comfortable heat, while the full spectrum heaters deliver stronger direct infrared warmth and help the sauna heat up faster.
Faster Heating Speed
Compared with an all-panel infrared sauna heater system, this hybrid kit can heat up approximately 30% faster. It is a great option for sauna rooms that need stronger heating performance.
Comfortable Sauna Experience
The carbon fiber panels create gentle far infrared heat, while the full spectrum heaters provide a more direct warming sensation. This balanced design helps create a more comfortable and effective sauna session.
Canadian Hemlock Wood Housing
Each full spectrum heater includes a Canadian hemlock wood housing, giving the installation a clean, natural, and professional sauna appearance.
Plug-and-Play C13 Wiring
This sauna heater kit includes 2-meter C13 connector wiring harnesses for easier installation. The plug-and-play style connection helps reduce wiring complexity.
Compatible With Our Sauna Controllers
This heater kit is compatible with all sauna controller models sold on our website. Please make sure the controller voltage and power rating match your installation before use.
Recommended Use
- DIY infrared sauna room builds
- Infrared sauna heater replacement
- Sauna heating system upgrades
- Traditional sauna conversion to infrared sauna
- Carbon fiber sauna panel replacement
- Full spectrum infrared sauna upgrades
- Custom home sauna repair projects
- Small to medium infrared sauna rooms
Recommended Sauna Room Size
This kit is recommended for sauna spaces up to:
| Metric Size | 1.5 × 1.3 × 1.9 m |
| Imperial Size | 4.9 × 4.3 × 6.2 ft |
| Approx. Volume | 3.7 m³ / 131 cu. ft. |
| Maximum Temperature | Approx. 65°C / 149°F |
Installation Notes
This kit is designed for easier DIY installation with C13 connector wiring. Before installation, please confirm that your sauna controller, voltage, circuit breaker, outlet, plug, and wiring are suitable for the total heater power.
If the installation only involves placing the heater modules and connecting compatible C13 plugs, many DIY users may be able to complete the installation. However, if your project involves main power wiring, electrical panel work, circuit upgrades, or voltage conversion, we recommend having the installation completed or inspected by a qualified electrician.
Always disconnect power before installation or maintenance.
FAQ
1. What size sauna room is this infrared heater kit suitable for?
This heater kit is recommended for sauna rooms up to approximately 1.5 × 1.3 × 1.9 m, or 4.9 × 4.3 × 6.2 ft. The maximum recommended room volume is about 131 cu. ft.
2. What is included in this sauna heater kit?
This kit includes 4 carbon fiber infrared heating panels, 3 full spectrum infrared heater modules, 3 Canadian hemlock wood housings, and 2-meter C13 connector wiring harnesses.
3. What is the total power of this infrared sauna heater kit?
The total power is approximately 2330W. The kit includes 4 carbon fiber panels at 320W each and 3 full spectrum heaters at 350W each.
4. What temperature can this sauna heater kit reach?
When installed in a properly sized and insulated sauna room, this heater kit can reach up to approximately 65°C / 149°F.
5. Is this kit faster than using only carbon fiber heating panels?
Yes. Because this kit combines carbon fiber heating panels with full spectrum infrared heaters, it can heat up approximately 30% faster than a heater kit using only carbon fiber panels.
6. What is the difference between carbon fiber panels and full spectrum infrared heaters?
Carbon fiber panels provide gentle and even far infrared heat. Full spectrum infrared heaters provide stronger direct infrared warmth and help the sauna heat up faster.
7. Can I use this kit for DIY sauna repair?
Yes. This kit is suitable for DIY infrared sauna repair, sauna heater replacement, sauna upgrades, and custom infrared sauna builds.
8. Is this heater kit plug-and-play?
This kit includes 2-meter C13 connector wiring harnesses for easier installation. It is designed as a plug-and-play style heater kit when used with compatible sauna controllers and proper wiring.
9. Is this kit compatible with your sauna controllers?
Yes. This infrared sauna heater kit is compatible with all sauna controller models sold on our website. Please make sure the controller power rating and voltage match your sauna setup.
10. Do I need an electrician to install this sauna heater kit?
Many DIY users can install the heater modules and connect the C13 wiring with a compatible controller. However, if the installation involves circuit changes, voltage changes, or main power wiring, we recommend using a qualified electrician for safety.
